Transmission 717.480/481/482/483 shifting mechanism design with selector drums and shift forks for 451.3/4 chassis.

Exploded view diagram of transmission shifting mechanism showing numbered components 1-9 and selector drums.

View full-size image ↗

See all Powertrain figures for the Fortwo (450), or browse the full figure library. Part numbers and callouts are community-sourced and cross-referenced against the manuals — confirm with your VIN before ordering.
