Seat heater (SIH) wiring diagram for model 451 chassis showing electrical circuit connections and component layout.

Wiring diagram for seat heater system with relays, switches, and electrical connections labeled.

View full-size image ↗

See all HVAC & Comfort figures for the Fortwo (450), or browse the full figure library. Part numbers and callouts are community-sourced and cross-referenced against the manuals — confirm with your VIN before ordering.
