Battery removal and installation procedure with part numbers for left and right-hand drive Smart 450/451 vehicles.

Battery removal steps and charging instructions for Smart vehicles with part numbers AR54.10-P-0005MCC and AR54.10-P-0005MCE.

View full-size image ↗

See all Electrical figures for the Fortwo (450), or browse the full figure library. Part numbers and callouts are community-sourced and cross-referenced against the manuals — confirm with your VIN before ordering.
