Auxiliary instruments wiring diagram for model 451 (except 451.391/491) up to 30.8.10, showing instrument cluster connections and circuit paths.

Wiring diagram with numbered callouts showing auxiliary instrument circuits, connectors, and ground points for smart 451.

View full-size image ↗

See all Electrical figures for the Fortwo (450), or browse the full figure library. Part numbers and callouts are community-sourced and cross-referenced against the manuals — confirm with your VIN before ordering.
