Fuse allocation chart for smart fortwo 453 with numbered positions, amperage ratings, and color coding for electrical system components.

Fuse box diagram showing 20 fuses with their locations, current ratings, and color codes for identification.

View full-size image ↗

See all Electrical figures for the Fortwo / Forfour (453), or browse the full figure library. Part numbers and callouts are community-sourced and cross-referenced against the manuals — confirm with your VIN before ordering.
