Overall electrical network diagram for Smart ForTwo/ForFour 453 showing chassis, CAN bus, and component locations.

Overhead view of Smart car with labeled electrical modules and wiring connections throughout chassis.

View full-size image ↗

See all Electrical figures for the Fortwo / Forfour (453), or browse the full figure library. Part numbers and callouts are community-sourced and cross-referenced against the manuals — confirm with your VIN before ordering.
