Door and rear-end hinge lubrication points on chassis 451.3/4 smart fortwo, with callout locations for hinges and locks.

See all Powertrain figures for the Fortwo (450), or browse the full figure library. Part numbers and callouts are community-sourced and cross-referenced against the manuals — confirm with your VIN before ordering.
