Power windows wiring diagram part 2 of 2 for 451 chassis, showing control circuits and component connections.

Wiring schematic for power window system with relays, switches, and connectors labeled.

View full-size image ↗

See all Electrical figures for the Fortwo (450), or browse the full figure library. Part numbers and callouts are community-sourced and cross-referenced against the manuals — confirm with your VIN before ordering.
