Transmission 717.470/471/474 removal/installation procedure for Smart Fortwo 454.03 with numbered callout locations.

Engine bay and transmission assembly diagram with 17 numbered callout points showing removal steps.

View full-size image ↗

See all Powertrain figures for the Fortwo / Forfour (453), or browse the full figure library. Part numbers and callouts are community-sourced and cross-referenced against the manuals — confirm with your VIN before ordering.
